A common problem found on the Z31 is a Clunk from the rear end of the car when shifting gears or accelerating/decelerating. This is usually caused by worn sub frame bushings and/or differential mount. Parts Needed. You can choose to replace the Parts with stock Rubber or upgrade to the Polyurethane replacements.

Handy Dandy Denny reference with ya Rough Idle’s Z Car Cheat Sheet This information is being provided free of charge to anyone that is interested in reading it. It has been compiled from ZCAR.COM, Web pages, and mailing lists on Z cars. When I find something good, I stick it in here. There is a lot of information here. Feel free to pass it on, edit it, and organize it, anything ya want. Just don’t try and sell it.

Disclaimer: This information is provided free of charge to anyone that is willing to request it. There is no warranty expressed or implied that this information is 100% fact. Use this information at your own risk. Verify anything that you feel is questionable. I am unable to be held responsible for anything that you decide to do with information. [ And ] Camaro Radiator Back when my car was L24 powered, it ran hot.

I took it to a mechanic who said that the guage was just reading high - not to worry. So, I motored on. Then the water pump fell off, the car instantly overheated, and, well, the of it is that the car is now L28 powered (L24 melted). So, in order to solve this problem, I did some digging around. If you look at the parts list at the site, there's a link to the radiator that they recommend (and resell at a premium) for a V8 Z with dimensions and everything.

I figured that if it's good enough to cool a big 350, it should work very nicely for an L28. So, I went to the local parts stores. They all only had the wide one.

There are two 85 camaro radiators, 951 and 952. One is 26' (too wide) and the other is 20' (just right). I don't have my info in front of me, but I think the 20' one is the 952. Scribblenauts Unlimited Free Online No Download. I got mine for $145 + $17 shipping (then minus a $50 coupon for total of $112!) from Carparts, vs. $225 plus shipping from JTR. I mounted it by holding it in place where it seemed to fit best, marking the holes (they are top and bottom since the tanks are on the side) and then drilling them (3/8' bit). Then I got 2 M8 60mm bolts put them thru the top holes, put the nuts on such that 1/4' of the ends of the bolts came thru.

I slid the radiator in place and hung it by the bolts in the top holes. Then I tacked the nuts in place. Cypress Touchpad Driver Windows 7 64 Bit. Did the same for the bottom of the radiator support.

The bottom holes end up being right at the very bottom edge - barely qualify as holes since there's like a sliver of metal left on the bottom of each one. Again, I tacked nuts in place. Then I took the radiator out and welded the nuts in securely. This is tricky since the threads can get screwed up by welding - I put a bolt in the nut before welding it in (not all the way!) and then right after I weld, I turn it back and forth. Anyway, with some 1 inch nylons spacers, everything fits perfectly.

There actually might be enough room to put a pusher elec. Fan in between the A/C condenser and the radiator. It's very thin and light. Fits very nicely. For hoses I sort of made some guestimates based on the original hoses and went to the local Advance Auto parts.

The guy let me peruse all the hoses and I came up with these: c71302 d71560 They both had to be trimmed a tad, but they fit beautifully. I don't know if those part numbers will translate well at other stores. The engine runs much cooler now than it did before. If you don't have access to a welder, JTR sells bracketry for mounting this radiator in a Z. - jeromio Differentials.

When checking the stamp on the ring rear, if you don't have 20/20 vision. Bring a magnifying glass. It really isn't easy to read. Also have a flashlight and some steel wool. Just in case ya need to do a bit of cleaning. A shop rag is required as well.

R180's and R200's with 3.364:1 gearing came in. 240 - 260 Z's / 1970 to 1974 - R180 280ZX 6/78 - 9/79 - R200 280ZX Automatics and turbo's - R200 Maxima Sedans Automatics - R180 Ring gear is stamped with 37:11 Math tip.

37 divided by 11 is 3.3636 R180's and R200's with 3.545:1 gearing came in. 240Z - 280ZX Automatics - R180 280Z Manual - R200 280ZX Turbo w/Automatics - R200 Maxima Sedan Manual - R180 Ring gear is stamped with 39:11 R180's and R200's with 3.70:1 gearing came in. 810 Sedan - R180 280ZX Manual from 6/78 to 6/79 - R200 300ZX Non-Turbo and Turbo's - R200 Ring gear is stamped with 37:10 R200 3.70:1 LSD – Clutch Pack – Finned Alum. Cover 300ZX Turbo only 1987-1989 R200 3.70:1 LSD Viscus 300ZX Turbo Only 1988 Cars are all White. Diff is Labeled. I’ve only heard of One person that knows How to install this in a 1 st Gen Z – 240Turbo on Zcar.com I have seen other comments on other mailing listed that indicated that the expense to do this conversion will out weigh the benefits of performing this swap.

Unless you have access to machine tool equipment, I would advise ya to swap to an lsd with clutch pack. Custom Mounting brakets – Dave in Portland, OR. Eric on the East Coast R180's and R200's with 3.90:1 gearing came in. 720 4X4 1/83 to 6/83 - R180 280ZX Non-Turbo 1980-1983 - R200 200SX Turbo 1984 - R200 200SX V6 - R200 Ring gear is stamped with 39:10 R180's and R200's with 4.11:1 gearing came in. 720 4X4 6/83 to 12/85 - R180 200SX Turbo 1985 to 1986 - R200 200SX Non-Turbo's 1984 to 1988 - R180 Ring gear is stamped with 37:9 This is only a reference guide.

Things do happen to cars and rear ends do get changed out. So always measure with rotation. I use chalk make a white mark on the driveshaft.

Do the same on the tire if its on, or whatever can be rotated. Place the mark at a point of reference. Like straight up or down. Then turn the drive shaft and count the turns. Do this for one full turn of the wheel/hub/rear half shaft.

This will give ya a good guess as to what gearing is in the rear end. When you find something close. Then pull the rear cover and start looking for the marking on the ring gear. New Body Parts – Fame Rails and body parts. Auto Rust Doctors 2728 Dover Road Bamber Lake NJ 08731 Phone Number: (609) 693-1631 Frame rails and floors with subframe repair panels. Regular shop for rust repair ONLY will install if you go to NJ.

Shown in the Wick Humble book. Front frame rails install in 8 hours. Weather Stripping Supplier Have you looked at Precision Replacement Parts?

Best known supplier is Nissan. Except for some differences the weather stripping will interchange from all years as long as you keep it from 2 str to 2 str and 2+2 to 2+2.

Www.240SXTECHDVDS.org & NIPerformance Has teamed up to make Nissan/Infinity Performance Parts. This is a clip of us installing ebay knock-off solid aluminum subframe bushings on a s14 subframe. Note* We are using a 600ft-lb impact gun set @ 95psi - you see how tuff they are to install! Plus if you look close the aluminum is actually peeling off a layer while it is pressing in the subframe! NIPeformance is in the making of a complete redesign of the solid aluminum subframe bushings for the Nissan s13-s14-Z32 chassis.

Check the website for all deatails!
